GE PMC-5565PIORC-210000

• Bus Compatibility: 33 MHz/66 MHz, 64-bit/32-bit compatible with PCI bus, supports both 3.3 V and 5.0 V signaling levels.
• Network Topology: Supports both ring and star topologies.
• Maximum Nodes: Up to 256 nodes in a single network.
• Data Packet Size: Automatically adjustable from 4 to 64 bytes.
• Data Transfer Rate: Up to 174 MB/s.
• Latency: As low as 0.4 microseconds.
• DMA Channels: Two independent DMA channels.
• Interrupt Support: Supports network interrupts with 32-bit data.
• Endian Conversion: Automatically handles endian conversion for different computer architectures within the same network.
• PIO Window: Configurable PIO window sizes from 2 MB to 64 MB, or up to the size of the onboard memory.
• Form Factor: Standard PMC half-length card.
• Operating Temperature: 0 °C to 65 °C (industrial-grade temperature range for reliable operation in harsh environments).
• Storage Temperature: -40 °C to 85 °C.
• Operating Systems Support: Windows, Linux, VxWorks, RTX, DOS, LabVIEW RT, RTX/RTX64, and other real-time operating systems.

Functional Characteristics of GE PMC-5565PIORC-210000:

• High-Speed, Real-Time Data Transmission: Utilizes a high-speed optical fiber network with a rate of 2.125 Gbps, enabling real-time data sharing across multiple nodes with minimal latency.
• CPU-Independent Operation: The network transmission process does not require CPU intervention, freeing up CPU resources for other critical tasks.
• Redundant Transmission Mode: Optional redundant transmission mode enhances data reliability and fault tolerance in mission-critical applications.
• Large Node Capacity: Supports up to 256 nodes, allowing for extensive system scalability and flexibility.
• Automatic Data Synchronization: When data is written to the memory of one node’s reflective memory card, it is automatically transmitted and synchronized across all other nodes in the network, ensuring data consistency.
• Flexible Network Configuration: Supports both ring and star topologies, enabling users to design networks according to specific application requirements.
• Easy to Use: The reflective memory technology simplifies data sharing by eliminating the need for complex software protocols, reducing development time and costs.
• Robust and Reliable: Designed for industrial environments with a wide operating temperature range and high resistance to electromagnetic interference.

Application Scenarios of GE PMC-5565PIORC-210000:

• Flight Simulators: Used in flight simulation systems to provide real-time data sharing between multiple simulation computers, ensuring synchronized and accurate simulation results.
• Automated Test Systems: Enables high-speed data acquisition and sharing in automated test equipment, improving test efficiency and accuracy.
• Marine and Submarine Simulators: Supports real-time data transmission in marine and submarine training simulators, providing a realistic training environment.
• Industrial Automation: Used in industrial control systems for real-time monitoring and control of manufacturing processes, enhancing production efficiency and quality.
• High-Speed Data Acquisition: Ideal for applications requiring high-speed data acquisition and processing, such as in scientific research and experimental setups.
• Power Plant Simulators: Facilitates real-time data sharing in power plant simulation systems, aiding in operator training and system optimization.
• Engine Test Benches: Used in engine testing to capture and analyze real-time data from multiple sensors, ensuring accurate performance evaluation.
• High-Speed Rail Transportation: Supports real-time data transmission in high-speed rail control systems, enhancing safety and operational efficiency.
