Allen-Bradley 2098-DSD-HV050X-DN Ultra 3000i Digital Servo Drive
The Allen-Bradley 2098-DSD-HV050X-DN is an ultra-reliable and efficient digital servo drive designed for industrial automation systems. It provides robust performance with high precision and versatility, making it ideal for manufacturing environments where precision control and reliability are paramount.
Input Voltage (AC):230 to 480V RMS, 3-Phase
Input Frequency (AC):47 to 63Hz
Nominal Input Current (AC):7A RMS
Continuous Output Current:11A (0-peak)
Intermittent Output Current:22A (0-peak)
Dimensions:9.54 x 14.2 x 5.46 in (242.2 x 360.7 x 138.7 mm)
Weight:10.44 kg (22.96 lbs)
Shunt-On Voltage:800V DC
Shunt-Off Voltage:750V DC
Interface:RS232, RS485, DeviceNet
Analog Inputs:1 for COMMAND, 1 for feedback
The Allen-Bradley 2098-DSD-HV050X-DN is a high-performance ultra 3000i digital servo drive. Designed with precision motion control in mind, this servo drive offers superior performance in industrial environments. Featuring a robust design, it is capable of handling intermittent output currents up to 22 amps and continuous output currents up to 11 amps. With a wide input voltage range from 230V to 480V, 3-phase, it is adaptable to various industrial applications.
The drive’s compact dimensions of 9.54 x 14.2 x 5.46 inches make it easy to integrate into existing systems without requiring significant space adjustments. It supports multi-turn absolute encoders, providing reliable feedback for accurate positioning. Additionally, the drive comes equipped with an RS232 and RS485 interface, supporting DeviceNet communication, which facilitates seamless integration with other devices in the network.
The 2098-DSD-HV050X-DN is built to withstand harsh industrial conditions. Its electromagnetic compatibility (EMC) standards compliance ensures reliable operation even in environments with strong electrical noise. The drive’s internal shunt resistance of 120 Ohms and shunt-on value of 800V DC further enhance its robustness and reliability.
Installation and maintenance of the Allen-Bradley 2098-DSD-HV050X-DN are straightforward, thanks to its user-friendly design. Whether you are upgrading your existing system or building a new one, this servo drive offers a reliable and efficient solution for all your motion control needs.
