Emerson IC800VMMCONP003 VersaMotion Motor Power and Brake Connector – 1kW and 2kW Models

Emerson IC800VMMCONP003 VersaMotion Motor Power and Brake Connector – 1kW and 2kW Models

    This VersaMotion series amplifier from Emerson provides a robust solution for a wide range of motion applications. It comes equipped with a built-in dynamic brake and supports stand-alone positioning capabilities with up to 8 stored motion profiles. The amplifier is designed for easy integration with analog motion controllers or pulse command interfaces.

Connector Type:MIL-DTL-515 Circular Connector with 17 pins

Power Rating:1 kW and 2 kW

Brake Holding Torque:12 nt-m

Brake Power Consumption:19.4 watts at 20°C

Brake Release Time:Max 10 ms

Brake Pull-In Time:Max 70 ms

Operating Temperature Range:-20°C to +60°C

Storage Humidity Range:20% to 90% non-condensing

Connection Interface:Amplifier with 20 terminal connector and locking screws

    The Emerson IC800VMMCONP003 is a robust motor power and brake connector designed for the VersaMotion series of amplifiers. This connector ensures reliable and efficient power delivery to your motor while providing a safe and controlled braking mechanism. With its advanced MIL-DTL-515 circular connector featuring 17 pins, it seamlessly connects to your amplifier’s 20 terminal interface with locking screws for secure connectivity.

    Built to withstand demanding industrial environments, this connector boasts a power rating of 1 kW and 2 kW, catering to a wide array of applications. The integrated brake system provides a holding torque of 12 nt-m, ensuring precise control over your motor operations. Additionally, it is equipped to handle operating temperatures ranging from -20°C to +60°C and can be stored in conditions with humidity levels between 20% and 90%, non-condensing.

    With its compatibility across various VersaMotion amplifiers and easy integration capabilities, the IC800VMMCONP003 enhances the overall efficiency and reliability of your industrial control systems. Its robust design and superior performance make it an indispensable component for professionals in the field of industrial automation.
