GE 350-E-P0-G0-H-E-E-N-N-SN-N-N Feeder Protection Relay, Advanced Protection Solutions

GE 350-E-P0-G0-H-E-E-N-N-SN-N-N Feeder Protection Relay, Advanced Protection Solutions

    The GE 350-E-P0-G0-H-E-E-N-N-SN-N-N is a feeder protection system designed for advanced protection against electrical faults in industrial settings. With a non-drawout design and comprehensive autoreclose functionality, it ensures reliable operation within demanding environments.

Breaker Control Operation Logic:Element, Virtual Input, Asserted Contact Input, Manual Command Contact Input Quantity 10

Ethernet Fiber Type:100 MB Multi-Mode

Form-A Relays Configuration:Two (2)

Neutral Overcurrent Time Delay:0.00 to 300.00 seconds in steps of 0.01

Neutral Timed Overcurrent ANSI Device:ANSI 51N

Power Magnetic Immunity Reference Standard:IEC61000-4-8

Autoreclose Reclose Attempts:Maximum of 4 Shots

Frequency Range:40.00 to 70.00 Hertz

Master Reset Password:8-10 Alphanumeric Characters

Number of Events Recorded:Up to 256

Oscillography Buffer Size:3 s

Sensitive Ground Time Overcurrent Pickup Level:0.005 to 3 x CT in steps of 0.001 x CT

    The GE 350-E-P0-G0-H-E-E-N-N-SN-N-N is an advanced feeder protection relay designed for industrial control systems. Its core function lies in providing precise protection and control over electrical systems, safeguarding against overcurrents and failures.

    Featuring a robust design with non-drawout configuration, this model is built to withstand harsh industrial environments, ensuring longevity and reliability. With a maximum of four autoreclose attempts, it supports uninterrupted system operation and enhanced safety standards.

    The relay includes two form-A relays, which are essential for ensuring accurate and timely responses to electrical faults. Additionally, it provides detailed data storage capabilities, allowing users to record up to 256 events and store oscillographic data for up to 3 seconds, facilitating in-depth analysis and troubleshooting.

    Equipped with a master reset password, this model ensures secure system access and control. The sensitive ground time overcurrent pickup level is adjustable, offering flexibility and precision in handling different scenarios.

    For ease of installation and maintenance, the 350-E-P0-G0-H-E-E-N-N-SN-N-N comes with a comprehensive set of I/O connections, including 10 inputs and 7 outputs, making it a versatile solution for modern industrial control applications.
