GE 369-HI-0-M-0-0-0 Motor Management Relay: Optimizing Motor Protection & Control
The GE Multilin 369-HI-0-M-0-0-0 is a motor management relay designed for efficient motor protection and control. It features an optional metering package and waveform capture capabilities to reduce maintenance costs and minimize downtime.
Control Power nominal:20 VA; maximum: 65 VA
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:approx. 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation Class:Class I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:approx. 4.5 kg
Communications:non-isolated RS232 port, RS485 port
Differential Switch Time Delay:<200 ms
Event Record Triggers:power fail, alarms, self test, inhibit, trip, waveform capture
Operating Range:-40°C (-40°F) to +60°C (140°F)
Storage Range:-40°C (-40°F) to +80°C (176°F)
The GE 369-HI-0-M-0-0-0 is a high-performance motor management relay designed to protect and manage industrial motors.
With its advanced metering capabilities and waveform capture technology, it offers unparalleled accuracy and reliability.
The optional metering package included in this model provides comprehensive monitoring and diagnostic data, enabling operators to make informed decisions and optimize motor performance.
Built with robust construction and reliable components, this relay can withstand harsh industrial environments and operate efficiently under demanding conditions.
Its compact design and user-friendly interface make it easy to install and maintain, reducing downtime and operational costs.
