GE Fanuc EF8210G34 Control Module – Industrial Automation

GE Fanuc EF8210G34 Control Module – Industrial Automation

    The ABB EF8210G34 Control Module is a highly reliable solution designed for industrial automation applications, ensuring seamless operation and superior performance.

Manufacturer:GE Fanuc

Model Number:EF8210G34

Module Type:Universal Analog Input Module

Channels:8

Filter Frequencies:6 hardware selectable filters

Calibration:Automatic

Input Types:Thermocouples, Strain Gauges, RTDs, Voltage, Current

Alarm Detection:High, High-High, Low, Low-Low

Power Supply:24 V DC

Operating Temperature Range:-20°C to +70°C

Dimensions:Width: 20 mm, Height: 90 mm, Depth: 125 mm

    The GE Fanuc RX3i EF8210G34 is a versatile 8-channel universal analog input module designed for integration with RX3i PCI bus systems. This module allows for seamless replacement of third-party modules due to its broad compatibility with various input types such as thermocouples, strain gauges, RTDs, voltage, and current inputs. Key features include full software configuration without the need for jumper settings, six hardware selectable filter frequencies, automatic calibration to correct module errors, and configurable alarm settings for high, high-high, low, and low-low thresholds. Users benefit from the module’s ability to detect open circuits in RTDs, set custom scaling ranges, and monitor temperature in either Celsius or Fahrenheit with user-configurable rate of change alarms. Additionally, each channel offers independent, configurable software filtering and interrupt options for alarms and faults. Terminal block insertion/removal detection ensures maintenance and operational integrity. The module supports on-board diagnostic functions, enhancing system reliability and providing real-time feedback through status LEDs. The compact design, with dimensions of 20mm width, 90mm height, and 125mm depth, makes it ideal for space-constrained installations.
