GE IC3600APAB1 Power Amplifying Card, Power Amplifier Module
The GE IC3600APAB1 is a power amplifying card designed by General Electric for use in their Mark I and Mark II industrial control systems. This component enhances and modifies electrical power or electronic signals, making it essential for critical applications.
Brand:General Electric
Model:IC3600APAB1
Power Amplification Capacity:High
Connector Type:Double Pronged Male Terminal Points
Number of Terminals:25
Transistor Configuration:Four small circular transistors in bent ‘U’ shaped brackets
Resistor Configuration:Eight large dark brown resistors and seven small dark brown resistors
LEDs:Two light emitting diodes (LEDs)
The GE IC3600APAB1 is meticulously crafted to enhance or modify electrical power or electronic signals within General Electric’s Mark I and Mark II control systems.
It is equipped with four small circular transistors, two of which are placed in bent U-shaped brackets for stability and efficiency. These transistors play a crucial role in signal modification processes.
The card is also fitted with eight large dark brown resistors and seven small dark brown resistors. These components help in regulating the flow of electrical energy, ensuring smooth operation and preventing overloads.
Two diodes, also known as LEDs, are integrated into the design. They emit light as energy passes through, providing real-time feedback on system status.
Connectivity is facilitated via twenty-five double-pronged male terminal points. These points include prongs that project horizontally and vertically, allowing for secure connections to other circuit boards.
Each component on the IC3600APAB1 is clearly labeled, including the General Electric insignia. This ensures easy identification and maintenance.
