GE SR469-P5-HI-A20-H: Advanced Motor Management Relay for Industrial Applications
The GE SR469-P5-HI-A20-H Motor Management Relay is designed to provide comprehensive protection and management for industrial motors. It features enhanced RTD inputs for temperature monitoring and conformal coating for extended durability in harsh environments.
Model Number:SR469-P5-HI-A20-H
CT Secondary Rating:5A
Optional Conformal Coating:Yes
RTD Inputs:Multiple (100 ohm Nickel, 120 ohm Nickel, 10 ohm Copper, 100 ohm Platinum)
Control Power Range:90-300 VDC, 70-265 VAC @ 48-62 Hz
Analog Outputs:4-20 mA
The GE SR469-P5-HI-A20-H is part of the 469 Multilin series, designed to provide robust motor management solutions for industrial environments. It features multiple RTD inputs to accurately measure temperature and the hottest point in the motor system, ensuring optimal performance and longevity.
This advanced relay supports 5A phase CT secondaries, allowing for precise current monitoring and control. It communicates via Modbus RTU protocol, enabling seamless integration with existing industrial automation systems.
The SR469-P5-HI-A20-H includes essential protective features such as torque protection, mechanical jam protection, undervoltage and overvoltage protection, and current unbalance correction. These features are highly configurable, allowing users to set specific thresholds and response times to suit their application needs.
The optional conformal coating provides enhanced protection against harsh environmental conditions, making it ideal for use in challenging industrial settings. Additionally, the Ethernet 10BaseT, RJ45 connection enables remote monitoring and data logging, facilitating efficient maintenance and troubleshooting.
Designed for ease of use and installation, the SR469-P5-HI-A20-H ensures reliable motor management and protection, reducing downtime and enhancing overall system reliability. Its robust design and versatile features make it a valuable asset for any industrial facility requiring precise motor control and protection.
