GE VMIVME-7696

• Storage:
  • IDE interface supporting 8 to 96 Mbyte bootable flash memory (optional).
  • Ultra-DMA-33 hard drive and floppy drive controller (connected via VMEbus P2).
• I/O Interfaces:
  • Two high-performance 16550-compatible serial ports.
  • Enhanced parallel port supporting ECP/EPP modes.
  • PS/2-style keyboard and mouse ports on the front panel.
  • USB port on the front panel.
• Networking: Onboard fast Ethernet controller supporting 10BaseT and 100BaseTX interfaces.
• SCSI: PCI Fast/Wide SCSI-2 interface with VMEbus P2 I/O (requires P2 SCSI terminator card, VMIACC-0561).
• Expansion: PMC mezzanine expansion interface (IEEE-P1386 standard, 5 V), supporting various PMC modules such as:
  • Fiber channel
  • Reflective memory
  • Analog and digital I/O
  • High-speed serial and parallel I/O
  • Network adapters (FDDI, ATM, 100BaseTX Ethernet, Fast Ethernet)
  • MIL-STD-1553 bus interface
  • Data acquisition cards
  • SCSI-2 adapters
• Timers: Three programmable 32-bit timers.
• Memory Backup: 128 Kbyte battery-backed SRAM.
• Watchdog Timer: Software-selectable watchdog timer with reset function.
• Remote Boot: Supports remote Ethernet boot using BootWare technology.
• Operating Systems: Windows NT, Windows 2000, VxWorks, Solaris, QNX, Linux.

Functional Characteristics of GE VMIVME-7696

• High Performance: Leverages the Pentium II processor’s advanced architecture for fast and efficient computing.
• Flexible Configuration: Supports a wide range of memory and storage options to meet different application requirements.
• Rich I/O Capabilities: Provides multiple serial, parallel, USB, and SCSI interfaces for connecting to various peripherals and devices.
• Enhanced Graphics: Integrated AGP SVGA controller with dedicated SGRAM for high-quality graphics display.
• Reliable Operation: Features a watchdog timer and battery-backed SRAM for data retention and system reliability.
• Easy Expansion: PMC mezzanine interface allows for easy integration of additional functionality through third-party PMC modules.
• Remote Management: Supports remote boot and network management for convenient system deployment and maintenance.

Application Scenarios of GE VMIVME-7696

• Simulation: Used in simulation systems for training and testing, providing high-performance computing and real-time data processing capabilities.
• Instrumentation: Ideal for various instrumentation applications requiring precise measurement and control.
• Industrial Control: Suitable for industrial automation and control systems, supporting real-time monitoring and control of machinery and equipment.
• Process Control and Monitoring: Used in process control and monitoring applications in chemical processing, oil and gas production, and water treatment.
• Factory Automation: Integrates into factory automation systems for intelligent networking and PLC control.
• Automatic Test: Supports automatic test equipment (ATE) for high-speed data acquisition and analysis.
• Data Acquisition: Provides high-speed data acquisition capabilities for research and development, as well as quality control applications.
