General Electric DS3800NCID1B1A – Network Control Board
The DS3800NCID1B1A is an essential printed circuit board designed for General Electric’s Mark IV industrial control systems. It plays a vital role in current isolation processes within these systems, ensuring reliable operation in demanding environments.
Manufacturer:General Electric
Model:DS3800NCID1B1A
Category:Industrial Control Boards
Compatibility:Mark IV Systems
Component Resistance:Varied resistances
Diodes:Multiple diodes
Integrated Circuits:Two integrated circuits with tiny components
Pin Connectors:2-pin four-position connectors labeled 01 through 03, P, and N
LEDs:Six light emitting diodes (LEDs)
Contact Points:Six contact points
Jumpers:Five jumpers settable to H or B
Resistors:Carbon composite and ceramic-covered metal film resistors
Capacitors:Various capacitor values
The DS3800NCID1B1A is a robust and reliable current isolator board manufactured by General Electric.
Designed specifically for integration into GE’s Mark IV turbine control systems, this board ensures precise management of electrical currents, enhancing system efficiency and safety.
It features multiple diodes, resistors, and capacitors to facilitate effective current isolation and protection against overloads.
Its compact design allows for easy installation in tight spaces, making it an ideal choice for various industrial environments.
Additionally, the board comes equipped with clearly labeled connectors and indicators, simplifying maintenance and troubleshooting processes.
