NI PXIE-5644R FPGA Module, Real-Time Processing

NI PXIE-5644R FPGA Module, Real-Time Processing

    The National Instruments PXIe-5644R RF Vector Signal Generator is a high-performance device designed for testing wireless communication systems. It offers a wide range of applications including RF component testing, system integration, and performance validation in aerospace, defense, and communications industries.

Manufacturer:National Instruments

Model Number:PXIe-5644R

Form Factor:PXI Express Module

Interface:PCI Express x4 Gen 1

Memory:Up to 1 GB DDR3 SDRAM

Clock Speed:125 MHz

Digital IO Channels:32

Analog Input Channels:8

Resolution:16-bit

Sampling Rate:Up to 20 MS/s per channel

Operating Temperature Range:-40°C to 85°C

    The NI PXIe-5644R is an essential tool for engineers working in wireless communications and radar systems. This module utilizes a high-performance FPGA for real-time signal processing and customization, enabling the creation of complex waveforms. Its compact form factor integrates seamlessly into existing PXI systems, making it ideal for both lab testing and field deployment. The high output power range and excellent phase noise performance ensure reliable signal integrity across a wide range of frequencies, from DC to 6 GHz. Moreover, the NI PXIe-5644R supports a variety of modulation schemes, providing unparalleled flexibility for RF signal generation. Designed with durability in mind, this signal generator is constructed with robust materials to withstand harsh environments, ensuring longevity and consistent performance over time. Whether you’re conducting rigorous R&D or deploying in the field, the NI PXIe-5644R is a reliable choice for your RF signal generation needs.
