NI PXIE-7858R High-Performance Reconfigurable FPGA Module

NI PXIE-7858R High-Performance Reconfigurable FPGA Module

    The NI PXIE-7858R is a high-performance real-time controller designed for demanding industrial applications. It offers advanced real-time data acquisition and processing capabilities, making it ideal for test and measurement systems, industrial automation, and research environments.

Module Type:Reconfigurable FPGA Module

Compatibility:PXI Express

Interface:PCIe Gen2 x4

Memory:Up to 1 GB DDR3 RAM

Programmable Logic:Xilinx Kintex UltraScale FPGA

Clock Speed:Up to 300 MHz

Analog Input Channels:Up to 4 channels

Digital I/O Channels:Up to 128 channels

Operating Temperature Range:-40°C to +85°C

    The NI PXIE-7858R is tailored for demanding industrial control systems requiring high-speed data acquisition and processing capabilities. Its core functionality lies in the Xilinx Virtex-7 FPGA, which provides the robustness needed for mission-critical applications. This FPGA module supports up to 8 GB DDR3 SDRAM, ensuring ample memory for complex operations. The 500 MHz clock speed enables swift execution of tasks, making it ideal for real-time signal processing. The module connects via 2×16-lane Gen2 PCIe, offering superior bandwidth for seamless data transfer. Designed for longevity and reliability, the PXIE-7858R includes comprehensive thermal management features to maintain optimal performance under heavy loads. Ideal for engineers and system designers looking to push the boundaries of what’s possible in industrial automation.
