NI SCXI-1335 Data Acquisition Module for Industrial Control Systems
The NI SCXI-1335 is a high-performance data acquisition module ideal for industrial automation and control systems. It features advanced signal conditioning capabilities, ensuring precise measurements in demanding environments.
Manufacturer:National Instruments
Model:SCXI-1335
Module Type:Signal Conditioning
Input Range:-10V to +10V
Common Mode Rejection Ratio (CMRR):120 dB
Gain:1x to 100x
Bandwidth:0 Hz to 10 kHz
Isolation Voltage:250 Vrms
Power Supply:24V DC
Channels:8 Differential or 16 Single-Ended
Connector Type:D-sub 37-pin
The National Instruments SCXI-1335 is a versatile signal conditioning module specifically tailored for industrial applications. It features eight differential channels capable of handling signals within a ±10V range, making it ideal for a wide variety of measurement scenarios. With an impressive common mode rejection ratio (CMRR) of 120 dB at DC, the SCXI-1335 ensures minimal interference from noise, thus enhancing the accuracy of your measurements.
This module includes robust isolation, rated up to 1500 Vrms, providing protection against electrical surges and ensuring reliable operation even in harsh environments. Its power supply requirements are ±15 Vdc ±5%, offering flexibility in system design and integration. The SCXI-1335 is built to withstand extreme temperatures, with an operating range from -40°C to +85°C, making it suitable for use in both indoor and outdoor settings.
Designed for seamless integration into existing National Instruments hardware platforms, the SCXI-1335 simplifies setup and configuration processes. Its compact form factor allows for efficient space utilization, making it perfect for densely packed industrial control panels. Whether you’re monitoring critical processes or performing precise measurements, the SCXI-1335 delivers the performance and reliability you need.
