Reliance Electric 86466-92S Rectifier Stack for Industrial Automation
The 86466-92S Rectifier Stack from Reliance Electric is an essential component for power conversion systems in industrial environments. It ensures efficient electrical energy transformation, making it indispensable for manufacturing and processing industries.
Input Voltage Range:120-480VAC
Output Voltage Range:0-480VDC
Frequency:50/60Hz
Max Power Rating:20kW
Cooling Method:Forced Air Cooling
Heat Sink Material:Aluminum
Fuses:2 x Ferraz Shawmut High-Speed Semiconductor Fuses
The 86466-92S Rectifier Stack is meticulously designed for industrial applications requiring high efficiency power conversion. Built with advanced SCR technology, it ensures reliable operation under demanding conditions.
This rectifier stack is constructed with durable materials to withstand harsh environments, featuring robust heat sinks for effective thermal management. The design incorporates a modular approach, making installation and maintenance straightforward.
Components within the stack are connected using high-quality braided wires, providing excellent conductivity and minimizing resistance. Two Ferraz Shawmut High-Speed Semiconductor fuses are mounted above the heat sink stacks for added protection against overcurrent.
The 86466-92S Rectifier Stack is compatible with a wide range of input voltages and delivers consistent output, making it suitable for various industrial control systems. Its compact size and lightweight design facilitate easy installation and space-saving mounting options.
For more detailed technical specifications and safety guidelines, please refer to the provided data sheets and manuals. AX Control offers a comprehensive warranty program and dedicated customer support to ensure your purchase meets all necessary standards.
