Rockwell Automation EK-15383 Linear Variable Differential Transformer
The Rockwell A-B EK-15383 Linear Variable Differential Transformer is a high-performance component designed for precise linear displacement measurement in industrial control systems. Its robust design and accuracy make it ideal for use in applications requiring reliable position sensing.
Manufacturer:Allen-Bradley
Model Number:EK-15383
Type:Linear Variable Differential Transformer (LVDT)
Measurement Range:±50 mm
Accuracy:±0.05% of Full Scale
Frequency Response:Up to 500 Hz
Output Signal:4-20 mA
Power Supply Voltage:10-30 VDC
Operating Temperature:-20°C to +85°C
Protection Rating:IP65
Weight:Approx. 0.5 kg
The A-B EK-15383 Linear Variable Differential Transformer is a robust solution for precision measurement needs. It is meticulously designed to deliver high accuracy in challenging industrial environments. Its construction utilizes durable materials ensuring longevity and reliability.
Key design highlights include its ability to withstand extreme temperatures and provide consistent performance under varying conditions. The transformer’s output is highly linear, making it suitable for applications where accuracy is paramount.
Installation is straightforward, with the M12 connector allowing for easy integration into existing systems. Its compact size makes it ideal for space-constrained installations without compromising on performance.
For optimal operation, the EK-15383 requires a supply voltage of 24V DC and can operate within a temperature range of -20°C to +85°C. The transformer’s output is calibrated for 4-20 mA, making it compatible with a wide range of control systems.
