GE 369-HI-R-M-0-0-0 Motor Management Relay with Optional Metering and RTD Inputs
The GE 369-HI-R-M-0-0-0-0 Motor Management Relay is designed to enhance the control and protection of medium to large motors. With its advanced features including waveform capture, event reporting, and data logging, it ensures efficient operation and reduced downtime.
Control Power nominal:20 VA
Control Power maximum:65 VA
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:approx. 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation:Class I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:approx. 4.5 kg
RTD Inputs:12 built-in RTD ports
Metering Feature:Optional metering package included
The GE 369-HI-R-M-0-0-0 is equipped with advanced metering capabilities and twelve built-in RTD ports, making it a robust solution for safeguarding and controlling medium-sized motors and their associated equipment.
This model leverages waveform capture technology to monitor motor performance in real-time, enabling proactive maintenance and reducing downtime. Event reports and data logging further enhance its diagnostic capabilities.
With a wide input voltage range, the relay can operate reliably across various electrical systems, ensuring consistent performance in diverse environments.
The built-in metering package provides precise monitoring of critical motor parameters, facilitating informed decision-making and operational optimization.
Designed with a durable construction and a compact form factor, the 369-HI-R-M-0-0-0 fits seamlessly into existing industrial setups, enhancing motor management without disrupting workflows.
