GE 369-HI-R-M-0-D-0-E – High-Performance Motor Management Relay

GE 369-HI-R-M-0-D-0-E – High-Performance Motor Management Relay

    The GE 369-HI-R-M-0-D-0-E is an advanced motor management relay designed for industrial control systems. It offers real-time monitoring and protection features including waveform capture, event reporting, and data logging to enhance system performance and reliability.

Control Power nominal:20 VA

Control Power maximum:65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:Approximately 12 in H x 5 in W x 8 in L

Weight:Approximately 4.5 kg

Insulation Class:Class I

Phase Current Input Conversion:True RMS, 1.04 ms/sample

Ground Current Input Frequency:20 to 100 Hz

Number of RTD Inputs:Twelve RTD Inputs

    The GE 369-HI-R-M-0-D-0-E Motor Management Relay is meticulously designed to monitor and manage industrial motors efficiently. With its advanced waveform capture technology, users can gain critical insights into motor performance and predict potential failures before they occur. The built-in event reporting and data logging functionalities further enhance the reliability and maintainability of your motor systems. The relay supports up to six digital or switch inputs, providing flexibility for various application scenarios. Designed to operate under harsh conditions, it is capable of handling ambient humidity up to 95% non-condensing and can function reliably at altitudes up to 2000 meters. This unit includes an optional metering package, which adds valuable metering capabilities, making it a comprehensive solution for motor management. The compact dimensions and lightweight design make installation straightforward and convenient, ideal for space-constrained environments. By integrating waveform capture, event reports, and data logging, the 369-HI-R-M-0-D-0-E significantly reduces maintenance costs and downtime, ensuring optimal motor operation and longevity.
